DP029-045ZPB10

Our ergonomic drill for the manual drilling into metal, wood, plastics and other materials.  This drill is used for the construction in the aviation- and automotive industry as well as the machine building industry. With pistolgrip design to absorb a higher torque. Without hoses. Our drill is robust, durable, and offers long working lifetimes.

Your advantages: For industrial applications, optimum power-to-weight ratio, ergonomic, simple operation

Objednací číslo
3027101A
Quick change drill chuck 0-6,5 mm
Max. power output 290 W / .39 hp
Speed (no load) 4500 min-1
Weight 1 kg / 2.20 lbs
Drive vane motor
Assortment Additional Assortment
Start trigger
Rotation right
Air consumption (no load) 0,65 m3/min / 22.95 cfm
Air consumption (loaded) 0,67 m3/min / 23.66 cfm
I.D. of air inlet hose 6 mm / .24 in
Chuck range 0,5-6,5 mm
Quick change drill chuck 0-6,5 mm
Taper DIN 238 B10
Drilling into steel to 4 mm / .16 in
Drilling into alu to 6 mm / .24 in
Air connection thread 1/4" male
Operating pressure 6,3 bar / 90 psi
Standard Equipment
Quick release coupling 804251
Nipple 323214
Drill chuck 0,5 - 6,5 mm/B10 804655
Quick-change drill chuck (capacity 0-6,5 mm/B10) 805986
Optional Accessories
Quick-change drill chuck (capacity 0-6,5 mm/B10) 805986
