DP060-060ZP3/8''
The 600-watt drill represents the next performance level within a comprehensive range of pistol grip drills. It is equipped with a speed regulator that maintains constant speed under load, accelerating the overall drilling process and reducing cycle times.
Excellent ergonomics of the grip areas ensure operator comfort, even in continuous multi-shift operations. The drill is particularly suited for horizontal drilling applications in the automotive, aerospace and mechanical engineering industries.
In general, the drill can be used for drilling into steel, aluminium and other materials.
Product number
6061155B
| Max. power output | 600 W / .80 hp |
|---|---|
| Speed (no load) | 6000 min-1 |
| Weight | 1,1 kg / 2.43 lbs |
| Drive | vane motor |
| Assortment | Additional Assortment |
| Start | trigger |
| Rotation | right |
| Air consumption (no load) | 0,55 m3/min / 19.42 cfm |
| Air consumption (loaded) | 0,98 m3/min / 34.60 cfm |
| I.D. of air inlet hose | 10 mm / .39 in |
| Max. drill-Ø | 10 mm / .39 in |
| Chuck range | 0,8-10 mm |
| Air connection | thread 1/4" female |
| Operating pressure | 6,3 bar / 90 psi |
Standard Equipment
| Spanner 12 mm |
|
800403 |
|---|---|---|
| Allen key 2 mm |
|
800443 |
| Plug 25SF AK 13 SXN |
|
6072224 |
