PLU50A-55ZK
Our air polisher with pistol-grip - for a fine-precision polishing - non-stop operation even when used in 24/7 operations.
With integrated speed regulator.
Objednací číslo
6060670A
| Max. power output | 450 W / .60 hp |
|---|---|
| Speed (no load) | 21000 min-1 |
| Weight | 0,75 kg / 1.65 lbs |
| Drive | vane motor |
| Assortment | Standard assortment |
| Start | trigger |
| Design | Pistolgrip Design |
| Rotation | right |
| Air consumption (no load) | 0,45 m3/min / 15.89 cfm |
| Air consumption (loaded) | 0,65 m3/min / 22.95 cfm |
| Max. radial speed of support disk | 55 m/s / 180.44 ft/s |
| Max. radial speed of grinding tip | 45 m/s / 147.64 ft/s |
| I.D. of air inlet hose | 10 mm / .39 in |
| Max. Ø of grinding tip | 35 mm / 1.38 in |
| Max. Ø of grinding insert | 9,5 mm / .37 in |
| Max. Ø of support disk | 50 mm / 1.97 in |
| Air connection | thread 1/4" female |
| Collets - clamping range | 6 [8; 9; 3/16''; 1/4''; 5/16'' ] mm |
| Spindle thread | M12x1 |
| Operating pressure | 6,3 bar / 90 psi |
Standard Equipment
| Collet ø 6 mm |
|
827910 |
|---|---|---|
| Spanner 12 mm |
|
800403 |
| Spanner 14 mm |
|
800410 |
| Plug 25SF AK 13 SXN |
|
6072224 |
Optional Accessories
| Collet ø 8 mm |
|
830704 |
|---|---|---|
| Collet ø 9 mm |
|
6014291 |
| Collet ø 1/4'' |
|
830705 |
| Collet ø 3/16'' |
|
6014287 |
| Collet ø 5/16'' |
|
830706 |
| Wrench ø 42 mm |
|
830701 |
