PV6A-B

Our ergonomic drill for the manual drilling into metal, wood, plastics and other materials.  This drill is used for the construction in the aviation- and automotive industry as well as the machine building industry. With pistolgrip design to absorb a higher torque. Without hoses. Our drill is robust, durable, and offers long working lifetimes.

Your advantages: For industrial applications, optimum power-to-weight ratio, ergonomic, simple operation

Objednací číslo
830500A
Max. power output 210 W / .28 hp
Speed (no load) 5000 min-1
Weight 0,7 kg / 1.54 lbs
Drive vane motor
Assortment Additional Assortment
Start trigger
Rotation right
Air consumption (no load) 0,6 m3/min / 21.19 cfm
Air consumption (loaded) 0,5 m3/min / 17.7 cfm
I.D. of air inlet hose 8 mm / .31 in
Chuck range 0,5-6 mm
Drilling into steel to 6 mm / .24 in
Drilling into alu to 6 mm / .24 in
Air connection thread 1/4" female
Spindle thread 3/8''x24
Operating pressure 6,3 bar / 90 psi
Standard Equipment
Spanner 8 mm 800399
Allen key 5 mm 800448
Drill chuck 830722
Hose Nozzle 830719
